一电蓄电池CFP2V系列主要用于通信系统（交换机、微波站、移动基站、数据中心、无线电及广播台站）；发电厂及输变电系统；太阳能和风力发电系统；信号系统和紧急照明系统。
一电蓄电池CFP2V系列
一电蓄电池FirstPower销售有限公司
标称电压：2V 额定容量：50AH to 3000AH 设计浮充寿命：20年（25℃）
一电电池型号 | 额定电压 | 额定容量 | 内阻 | 外型规格（mm/in） | ||||||||
长 | 宽 | 高 | 总高 | |||||||||
mm | in | mm | in | mm | in | mm | in | 型号 | ||||
CFP2100 | 2 | 100 | 0.8 | 171 | 6.7 | 72 | 2.8 | 206 | 8.1 | 209 | 8.2 | T11 |
CFP2200 | 2 | 200 | 0.9 | 173 | 6.8 | 109 | 4.3 | 330 | 13 | 364 | 14.3 | T10 |
CFP2250 | 2 | 250 | 0.75 | |||||||||
CFP2300 | 2 | 300 | 0.75 | 171 | 6.7 | 151 | 5.9 | 330 | 13 | 364 | 14.3 | T10 |
CFP2350 | 2 | 350 | 0.65 | |||||||||
CFP2400 | 2 | 400 | 0.6 | 210 | 8.3 | 171 | 6.9 | 330 | 13 | 367 | 14.4 | T10 |
CFP2450 | 2 | 450 | 0.5 | |||||||||
CFP2500 | 2 | 500 | 0.5 | 241 | 9.5 | 171 | 6.7 | 330 | 13 | 365 | 14.4 | T10 |
CFP2550 | 2 | 550 | 0.45 | |||||||||
CFP2600 | 2 | 600 | 0.45 | 302 | 11.9 | 175 | 6.9 | 330 | 13 | 367 | 14.4 | T10 |
CFP2800 | 2 | 800 | 0.35 | 410 | 16.1 | 175 | 6.9 | 330 | 13 | 367 | 14.4 | T10 |
CFP21000 | 2 | 1000 | 0.28 | 475 | 18.7 | 175 | 6.9 | 330 | 13 | 367 | 14.4 | T10 |
CFP21200 | 2 | 1200 | 0.25 | |||||||||
CFP21500 | 2 | 1500 | 0.2 | 400 | 15.7 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 |
CFP22000 | 2 | 2000 | 0.18 | 490 | 19.3 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 |
CFP22400 | 2 | 2400 | 0.15 | |||||||||
CFP23000 | 2 | 3000 | 0.11 | 710 | 28 | 350 | 13.8 | 345 | 13.6 | 382 | 15 | T10 |
一电蓄电池FirstPower销售有限公司
一电电池型号 | 额定电压 | 额定容量 | 内阻 | 外型规格（mm/in） | ||||||||
长 | 宽 | 高 | 总高 | |||||||||
mm | in | mm | in | mm | in | mm | in | 型号 | ||||
CFP2200S | 2V | 200 | 0.8 | 206 | 8.1 | 103 | 4.1 | 355 | 14 | 390 | 15.4 | T10 |
CFP2250S | 2V | 250 | 0.75 | 206 | 8.1 | 124 | 4.9 | 355 | 14 | 390 | 15.4 | T10 |
CFP2300S | 2V | 300 | 0.7 | 206 | 8.1 | 145 | 5.7 | 355 | 14 | 390 | 15.4 | T10 |
CFP2350S | 2V | 350 | 0.65 | 206 | 8.1 | 124 | 4.9 | 471 | 18.5 | 506 | 19.9 | T10 |
CFP2400S | 2V | 400 | 0.55 | 206 | 8.1 | 145 | 5.7 | 471 | 18.5 | 506 | 19.9 | T10 |
CFP2500S | 2V | 500 | 0.45 | 206 | 8.1 | 166 | 6.5 | 471 | 18.5 | 506 | 19.9 | T10 |
CFP2600S | 2V | 600 | 0.4 | 206 | 8.1 | 145 | 5.7 | 646 | 25.4 | 681 | 26.8 | T10 |
CFP2770S | 2V | 770 | 0.35 | 253 | 10 | 210 | 8.3 | 471 | 18.5 | 506 | 19.9 | T10 |
CFP2800S | 2V | 800 | 0.35 | 210 | 8.3 | 191 | 7.5 | 646 | 25.4 | 681 | 26.8 | T10 |
CFP21000S | 2V | 1000 | 0.3 | 233 | 9.2 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 |
CFP21200S | 2V | 1200 | 0.25 | 275 | 10.8 | 210 | 8.3 | 646 | 25.4 | 681 | 26.8 | T10 |
CFP21500S | 2V | 1500 | 0.2 | 275 | 10.8 | 210 | 8.3 | 796 | 31.3 | 831 | 32.7 | T10 |
CFP22000S | 2V | 2000 | 0.18 | 399 | 15.7 | 210 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 |
CFP22500S | 2V | 2500 | 0.15 | 487 | 19.2 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 |
CFP23000S | 2V | 3000 | 0.12 | 576 | 22.7 | 212 | 8.3 | 772 | 30.4 | 807 | 31.8 | T10 |
